MIL-PRF-19500/118L
Dimensions
Symbo
Type
Inches
Millimeters
Notes
Min
Max
Min
Max
BD
.055
.107
1.40
2.72
3
1N483B
BL
.120
.300
3.05
7.62
1N485B
1N486B
LD
.018
.022
0.46
0.56
2, 5
(DO-7/35)
LL
1.00
1.500
25.40
38.10
4, 5
BD
.056
.075
1.42
1.90
1N5194
BL
.120
.180
3.05
4.57
1N5195
1N5196
LD
.018
.022
0.46
0.56
2, 5
(DO-35)
LL
1.00
1.500
25.40
38.10
4, 5
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Dimension BD shall be measured at the largest diameter.
4. The minimum dimension of BD shall apply over at least .065 inch (1.65 mm) of dimension BL.
5. The specified lead diameter applies in the zone between .050 inch (1.27 mm) from the diode body to the end
of the lead. Outside of this zone lead shall not exceed BD. Applies to both leads.
6. In accordance with ASME Y14.5M, diameters are equivalent to x symbology.
FIGURE 1. Physical dimensions (DO-7, DO-35).
3
