MILPRF19500/124L
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activities within the Military Service or Defense Agency, or
within the Military Service's system commands. Packaging data retrieval is available from the managing Military
Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.
The notes specified in MILPRF19500 are applicable to this specification.)
6.1 Intended use. Semiconductors conforming to this specification are intended for original equipment design
applications and logistic support of existing equipment.
6.2 Acquisition requirements. Acquisition documents should specify the following:
a.
Title, number, and date of this specification.
b.
Packaging requirements (see 5.1).
Lead finish (see 3.4.1).
c.
d.
Product assurance level and type designator.
6.3 Qualification. With respect to products requiring qualification, awards will be made only for products which are,
at the time of award of contract, qualified for inclusion in Qualified Manufacturers List (QML19500) whether or not
such products have actually been so listed by that date. The attention of the contractors is called to these
requirements, and manufacturers are urged to arrange to have the products that they propose to offer to the Federal
Government tested for qualification in order that they may be eligible to be awarded contracts or orders for the
products covered by this specification. Information pertaining to qualification of products may be obtained from
DLA Land and Maritime, ATTN: VQE, P.O. Box 3990, Columbus, OH 43218-3990 or e-mail vqe.chief@dla.mil.
An online listing of products qualified to this specification may be found in the Qualified Products Database (QPD) at
6.4 Substitution information. Devices covered by this specification are substitutable for the manufacturer's and
user's Part or Identifying Number (PIN). This information in no way implies that manufacturer's PINs are substitutable
for the military PIN.
Preferred types military PIN
Superseded PIN
Commercial PIN
JAN, JANTX, JANTXV, JANS1N2970B
1N3999A
1N2970B
JAN, JANTX, JANTXV, JANS1N2970RB
1N3999RA
1N2970RB
JAN, JANTX, JANTXV, JANS1N2971B
1N4000A
1N2971B
JAN, JANTX, JANTXV, JANS1N2971RB
1N4000RA
1N2971RB
6.4.1 Obsoleted part numbers. MILS19500/272 for Part or Identifying Number (PIN) 1N3993A, RA through
1N4000A, RA are obsolete. PINs 1N3993A, RA through 1N3998A, RA have been incorporated into
MILPRF19500/124. PINs 1N3999A, RA and 1N4000A, RA have been deleted, as they are redundant to
1N2970RB, B and 1N2971RB, B respectively.
12
