MIL-PRF-19500/304E
5. PACKAGING
* 5.1 Packaging. For acquisition purposes, the packaging requirements should be as specified in the contract or
order (see 6.2). When packaging of material is to be performed by DoD personnel, these personnel need to contact
the responsible packaging activity to ascertain requisite packaging requirements. Packaging requirements are
maintained by the Inventory Control Points' packaging activity within the Military Department or Defense Agency, or
within the Military Departments' System Command. Packaging data retrieval is available from the managing Military
Departments' or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
6. NOTES
* (This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.)
The notes specified in MIL-PRF-19500 are applicable to this specification.
* 6.1 Intended use. Semiconductors conforming to this specification are intended for original equipment design
applications and logistic support of existing equipment.
* 6.2 Acquisition requirements. Acquisition documents should specify the following:
a.
Title, number, and date of this specification.
b.
Packaging requirements (see 5.1).
c.
Lead finish (see 3.4.1).
d.
Product assurance level and type designator.
e.
For die acquisition, the letter version shall be specified (see figure 3).
* 6.3 Qualification. With respect to products requiring qualification, awards will be made only for products which are,
at the time of award of contract, qualified for inclusion in Qualified Manufacturer's List (QML-19500) whether or not
such products have actually been so listed by that date. The attention of the contractors is called to these
requirements, and manufacturers are urged to arrange to have the products that they propose to offer to the Federal
Government tested for qualification in order that they may be eligible to be awarded contracts or purchase orders for
the products covered by this specification. Information pertaining to qualification of products may be obtained from
DLA Land and Maritime, ATTN: VQE, Columbus, OH 43216 or e-mail vqe.chief@dla.mil. An online listing of
products qualified to this specification may be found in the Qualified Products Database (QPD) at
6.4 Supersession data. The following types were superseded through a previous revision of this specification and
the cancellation of MIL-S-19500/266. A-version devices may be substituted for Non A-version devices. Applicable
substitutes are as follows:
Superseded types
Substitute types
1N3874, 1N3875, 1N3884
1N3885
1N3876
1N3886
1N3877, 1N3878, 1N3887
1N3888
1N3879, 1N3880, 1N3889
1N3890
1N3879R, 1N3880R, 1N3889R
1N3890R
1N3881
1N3891
1N3881R
1N3891R
1N3882, 1N3883, 1N3892
1N3893
1N3882R, 1N3883R, 1N3892R
1N3893R
NOTE: Superseded types shall not be used for new design.
