MIL-PRF-19500-355 Semiconductor Device, Unitized Dual Transistor, Npn, Silicon, Types 2N2919, 2N2920, 2N2919L, 2N2920L, 2N2919U, And 2N2920U, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhc, Janhcm, Janhcd, Janhcp, Janhcl, Janhcr, Janhcf, Janhcg, Janhch, Jankc, Jankcm, Jankcd, Jankcp, Jankcl, Jankcr, Jankcf, Jankcg, And JankchThis specification covers the performance requirements for two electrically isolated, matched NPN silicon transistors as one dual unit. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type die. RHA level designators "M", "D", "P", "L", "R", "F", "G" and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. .
MIL-PRF-19500/355R
1.4 Primary electrical characteristics of each individual section. Unless otherwise specified, TC =+25°C.
hFE1
|hfe|
VCE(SAT)
VCE = 5 V dc
VCE = 5 V dc
IC = 1 mA dc
IC = 10 µA dc
IB = 100 µA dc
IC = 0.5 mA dc
2N2919 2N2919L
2N2920 2N2920L
f = 20 MHz
2N2919U
2N2920U
V dc
Min
60
175
3.0
Max
240
600
20
0.3
1.5 Primary electrical matching characteristics of each individual section. Unless otherwise specified, TC =+25°C.
*
|Ć(VBE1 - VBE2)ĆTA |1
|Ć(VBE1 - VBE2)ĆTA |2
|VBE1 - VBE2 |1
hFE 2-1
hFE 2-2
VCE = 5 V dc
VCE = 5 V dc
VCE = 5 V dc
VCE = 5 V dc
IC = 10 µA dc
IC = 100 µA dc
IC = 100 µA dc
IC = 100 µA dc
TA = +25°C and -55°C
TA = +125°C and +25°C
(1)
mV dc
mV dc
mV dc
Min
0.9
Max
1.1
5
0.8
1.0
*
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-19500
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-750
-
Test Methods for Semiconductor Devices.
*  (Copies of these documents are available online at https://assist.dla.mil/quicksearch or https://assist.dla.mil or
from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the
text of this document and the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
