MIL-PRF-19500/421G
* TABLE I. Group A inspection.
MIL-STD-750
Symbol
Limit
Unit
Inspection 1/
Method
Conditions
Min
Max
Subgroup 1 2/
n = 45 devices, c = 0
Visual and mechanical
2071
examination 3/
n = 15 leads, c = 0
Solderability 3/
2026
n = 15 devices, c = 0
Resistance to solvents
1022
3/ 4/
Test condition C, 25 cycles
Temp cycling 3/
1051
n = 22 devices, c = 0
n = 22 devices, c = 0
Heremetic seal
1071
Fine leak
Gross leak
Table I, subgroup 2
Electrical measurements
2037
Precondition TA = +250°C at t = 2 hrs, n
Bond strength 3/
= 11 wires, c = 0
Subgroup 2
°C/W
Thermal impedance
3131
See 4.3.3
ZθJX
µA dc
Bias condition D; VCB = 60 V dc
10
3036
Collector to base
ICBO1
cutoff current
Bias condition D; IC = 10 mA dc;
Breakdown voltage,
40
V dc
3011
V(BR)CEO
pulsed (see 4.5.1)
collector to emitter
µA dc
Bias condition D; VEB = 5 V dc
10
3061
Emitter to base cutoff
IEBO1
current
Bias condition D; VCB = 50 V dc
3036
Collector to base
ICBO2
cutoff current
2N3838
50
nA dc
2N4854
10
nA dc
2N4854U
10
nA dc
10
nA dc
3061
Emitter to base cutoff
Bias condition D; VEB = 3 V dc
IEBO2
current
VCE = 1 V dc; IC = 150 mA dc;
50
3076
Forward-current
hFE1
pulsed (see 4.5.1)
transfer ratio
VCE = 10 V dc; IC = 100 µA dc
35
3076
Forward-current
hFE2
transfer ratio
VCE = 10 V dc; IC = 1.0 mA dc
50
3076
Forward-current
hFE3
transfer ratio
See footnotes at end of table.
10
