MIL-PRF-19500-455 Semiconductor Device, Transistor, Npn, Silicon, Power Switching, Types 2N5664, 2N5665, 2N5666, 2N5666S, 2N5666U3, 2N5667, And 2N5667S, Jan, Jantx, Jantxv, Jantxvr, Jantxvf, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhc, And Jankc, Jankcm, Jankcd, Jankcp, Jankcl, Jankcr, Jankcf, Jankcg, And JankchThis specification covers the performance requirements for NPN, silicon, power transistors for use in high-speed power-switching applications. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each un-encapsulated device type as specified in MIL-PRF-19500. Provisions for radiation hardness assurance \(RHA\) to eight radiation levels is provided for JANS product assurance level. Radiation hardness assurance \(RHA\) level designators; "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/455K

TABLE II. Groups B, C, and E delta measurements. 1/ 2/ 3/ 4/

Steps

Inspection

Symbol

Limits

Unit

Method

Conditions

Min

Max

ĆICES1

Collector to emitter

3041

Base condition C

100 percent of initial

cutoff current

value or 20 nA dc,

whichever is greater.

VCE = 200 V dc

2N5664, 2N5666, 2N5666S,

and 2N5666U3

VCE = 300 V dc

2N5665, 2N5667, 2N5667S

�25 percent change

ĆhFE2 5/

Forward-current

3076

VCE = 5 V dc, IC = 1.0 A dc

transfer ratio

from initial reading.

pulsed (see 4.5.1)

1/ The delta measurements for table E-VIA (JANS) of MIL-PRF-19500 are after subgroups 4 and 5, and consist

of steps 1 and 2 of table II herein.

2/ The delta measurements for table E-VIB (JAN, JANTX, and JANTXV) of MIL-PRF-19500 are as follows:

Subgroups 3 and 6, see table II herein, steps 1 and 2.

3/ The delta measurements for table E-VII of MIL-PRF-19500 are as follows:

Subgroup 6, see table II herein, steps 1 and 2.

4/ The delta measurements for table E-IX of MIL-PRF-19500 are as follows:

Subgroups 1 and 2, see table II herein, steps 1 and 2.

5/ Measured at less than .125 inch (3.175 mm) from case.
