MIL-PRF-19500/455K
* TABLE I. Group A inspection - Continued.
Inspection 1/ 2/
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 4
Magnitude of common-emitter,
3306
2.0
7.0
| hfe |
VCE = 5 V dc, IC = 0.5 A dc,
small-signal short-circuit,
f = 10 MHz
forward-current, transfer ratio
Open-circuit output
3236
120
pF
VCB = 10 V dc,
Cobo
capacitance
100 kHz ≤ f ≤ 1 MHz
Pulse response
µs
Turn-on time
3251
0.25
Test condition A; IC = 1.0 A dc,
ton
VCC = 100 V dc
2N5664, 2N5666, 2N5666S
See figure 16
*
2N5665, 2N5667, 2N5667S
See figure 17
*
Turn-off time
3251
Test condition A; IC = 1.0 A dc,
toff
VCC = 100 V dc
µs
2N5664, 2N5666, 2N5666S
See figure 16
1.5
*
µs
2N5665, 2N5667, 2N5667S
See figure 17
2.0
*
Subgroup 5
TC = + 100°C, t ≥ 1 s, 1 cycle;
Safe operating area
3051
(continuous dc) (for types
*
2N5664 and 2N5665 only)
Test #1
VCE = 6 V dc, IC = 5 A dc
2N5664 and 2N5665
Test #2
2N5664
VCE = 32 V dc, IC = 0.75 A dc
2N5665
VCE = 40 V dc, IC = 0.75 A dc
Test #3
VCE = 200 V dc, IC = 29 mA dc
2N5664
2N5665
VCE = 300 V dc, IC = 21 mA dc
See footnotes at end of table.
