The documentation and process conversion
INCH-POUND
measures necessary to comply with this revision
MIL-PRF-19500/461F
shall be completed by 30 August 2008
30 May 2008
SUPERSEDING
MIL-PRF-19500/461E
18 April 2003
*
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, HIGH-POWER,
TYPE 2N6211, 2N6212, 2N6213, 2N6213A, JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP silicon, high-voltage. Four levels of
product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product
assurance are provided for each unencapsulated device type.
1.2 Physical dimensions. See figure 1 (TO-66), and figure 2, JANHC and JANKC (die) dimensions.
1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
Type
ZθJX
RθJC
TJ and
IC
IB
VEBO
VCEO
PT (1)
PT (2)
VCBO
TA = +25°C
TC = +25°C
(max)
TSTG
°C
°C/W
°C/W
W
W
V dc
V dc
V dc
A dc
A dc
2N6211
3.0
35
275
225
6.0
1.0
2.0
-65 to +200
5.0
1.75
2N6212
3.0
35
350
300
6.0
1.0
2.0
-65 to +200
5.0
1.75
2N6213
3.0
35
400
350
6.0
1.0
2.0
-65 to +200
5.0
1.75
2N6213A
3.0
35
500
450
6.0
1.0
2.0
-65 to +200
5.0
1.75
Derate linearly at 17.1 mW/°C for TA > +25°C.
(1)
Derate linearly at 200 mW/°C for TC > +25°C.
(2)
1.4 Primary electrical characteristics. Unless otherwise specified, TC = +25°C.
Pulse
hFE1 (1)
VCE(SAT) (1)
Cobo
|hfe|
response
100 kHz ≤ f ≤ 1 MHz
f = 5 MHz
Limit
VCE = 5 V dc
IC = 1.0 A dc
ton
toff
IC = 0.2 A dc
VCB = 10 V dc
IB = -0.125 A dc
VCE = 10 V dc
2N6211
2N6213A
IE = 0
IC = 1 A dc
2N6212
2N6211
2N6212
2N6213
2N6213A
2N6213
μs
μs
V dc
V dc
V dc
pF
Minimum
30
4
1.5
Maximum
175
1.4
1.6
2.0
220
20
10
0.6
3.1
(1) Pulsed (see 4.5.1).
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
