MIL-PRF-19500/461F
* TABLE I. Group A inspection - Continued.
1/
MIL-STD-750
Limit
Unit
Inspection
Symbol
Method
Conditions
Min
Max
Subgroup 5 - Continued.
Safe operating area
3053
Load condition C (unclamped
(switching)
inductive load) (see figure 5) TC =
+25°C, duty cycle ≤ 10 percent
tp ≈ 15 ms, RBB1 = 20 Ω, VBB1 = 10
Test 1
V dc maximum, RBB2 = 20 Ω, VBB2
= 1.5 V dc, VCC = 10 V dc, IC = 2 A
dc, L = 25 μH, RS = 0.1Ω
tp ≈ 15 ms, RBB1 = 50 Ω, VBB1 = 10
Test 2
V dc maximum, RBB2 = 20 Ω, VBB2
= 1.5 V dc, VCC = 10 V dc, IC =
0.25 A dc, L = 3.0 mH, RS = 1.0 Ω
Electrical measurements
See table I, subgroup 2
Safe operating area
3053
Load condition B, (clamped
(switching)
inductive load) see figure 6, TC =
+25°C, duty cycle ≤ 10 percent, tp
≈ 15 ms, RS = 0.1 Ω, RBB1 = 20 Ω,
RBB2 = 20 Ω, VBB1 = 10 V dc
maximum, VBB2 = 1.5 V, IC = 2.0
A dc (clamped voltage must be
reached)
VCC = 225 V dc, RL ≤ 112.5 Ω
2N6211
VCC = 300 V dc, RL ≤ 150 Ω
2N6212
VCC = 350 V dc, RL ≤ 175 Ω,
2N6213, 2N6213A
L = 250μH, CR = 1N1190A
2N6211
Clamp voltage = 225, +0, -5 V dc
2N6212
Clamp voltage = 300, +0, -5 V dc
2N6213, 2N6213A
Clamp voltage = 350, +0, -5 V dc
Electrical measurements
See table I, subgroup 2
1/
For sampling plan, see MIL-PRF-19500.
2/
This test required for the following end-point measurements only:
*
Group B, subgroups 2 and 3 (JAN, JANTX, JANTXV).
Group B, subgroups 3 and 4 (JANS).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
