MIL-PRF-19500/477K
1.3.2 Ratings applicable to individual types - Continued.
(1) TEC = TL at L = 0 or Tend tab for US suffix devices.
(2) Derate at 25 mA/°C for TL above +75°C for 2.5 amp ratings.
(3) Derate at 60 mA/°C for TL above +75°C for 6.0 amp ratings.
(4) For the 1 and 3 amp ratings at 55°C, these IO ratings are for a thermally (PC boards or other) mounting methods
where the lead or end-cap temperatures cannot be maintained as shown in col. 3 of 1.3.2 and where the
thermal resistance from mounting point to ambient is still sufficiently controlled where TJ(MAX) in 1.3.1 is not
exceeded. This equates to RθJX ≤ 154ºC/W for the 1N5802 - 1N5806 and RθJX ≤ 52ºC/W for the 1N5807 -
(5) Derate at 8.33 mA/°C for TA above +55°C for 1.0 amp ratings.
(6) Derate at 25 mA/°C for TA above +55°C for 3.0 amp ratings.
(7) US suffix devices only.
1.4 Primary electrical characteristics. Unless otherwise specified, TA = +25°C.
IR1 at VR = VRWM
IR2 at VR = VRWM
Types
TA = +25°C,
TA = +125°C,
VBR at 100 µA,
pulse ≤ 20 ms
pulsed VR ≤ 20 ms
pulsed VR ≤ 20 ms
µA
µA
V
1N5802, US, URS
60
1.0
175
1N5804, US, URS
110
1.0
175
1N5806, US, URS
160
1.0
175
1N5807, US, URS
60
5.0
525
1N5809, US, URS
110
5.0
525
1N5811, US, URS
160
5.0
525
2
