MIL-PRF-19500/495G
1 June 2010
SUPERSEDING
MIL-PRF-19500/495F
25 March 2009
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, UNITIZED, DUAL-TRANSISTOR, NPN, SILICON
TYPES 2N5793, 2N5794, AND 2N5794U, 2N5794UC, 2N5793A, 2N5794A,
2N5794AU, AND 2N5794AUC, JAN, JANTX, JANTXV, JANS, JANSM,
JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, AND JANSH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for unitized, dual transistors which contains a
pair of electrically isolated unmatched NPN, silicon transistors in one package. Four levels of product assurance are
provided for each device type as specified in MIL-PRF-19500. RHA level designators "M", "D", "P", "L", "R", "F", "G",
and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.
1.2 Physical dimensions. See figure 1 (similar to TO-99), and 2, and 3 (surface mount U and UC).
*
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
PT (1)
IC
VCBO
VCEO
VEBO
TSTG and TJ
TA = +25°C
One
Both
section
sections
mW
mW
mA dc
V dc
V dc
V dc
°C
500
600
600
75
40
6.0
-65 to +200
RθJA
RθJA
RθJSP
RθJSP
RθJPCB
RθJPCB
Types
One section
One section
One section
Both sections
Both sections
Both sections
°C/W (2)
°C/W (2)
°C/W (2)
°C/W (2)
°C/W (2)
°C/W (2)
2N5793, 2N5794
350
290
2N5793A, 2N5794A
350
290
2N5794U, 2N5794UC
110
90
350
290
2N5794AU, 2N5794AUC
110
90
350
290
See notes on next page.
