MIL�PRF�19500/539F

TABLE II. Group E inspection (all quality levels) � for qualification and re-qualification only.

MIL�STD�750

Qualification

Inspection

sample plan

Method

Conditions

Subgroup 1

45 devices; c = 0

Temperature cycling

1051

500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2 herein.

Subgroup 2

45 devices; c = 0

Test temperature = +125�C; VCB = 80

Blocking life

1048

percent rated; T = 1,000 hours.

Electrical measurements

See table I, subgroup 2 herein.

Sample size N/A

Subgroup 4

Thermal impedance curves

See MIL�PRF�19500.

Subgroup 5

3 devices; c = 0

Barometric pressure

1001

Test condition C. See 1.3.

(reduced)

Subgroup 6

11 devices

Electrostatic discharge

1020

sensitivity classification

Subgroup 8

45 devices; c = 0

Reverse voltage leakage

1033

Condition B for all device types.

stability
