MILPRF19500/539F
TABLE I. Group A inspection.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 1
Visual and mechanical
2071
examination
Subgroup 2
Thermal impedance 2/
3131
See 4.3.1
°C/W
ZθJX
Bias condition D, IC = 100 mA dc;
V(BR)CEO
Breakdown voltage,
3011
collector to emitter
pulsed (see 4.5.1)
2N6300
60
V dc
2N6301
80
V dc
Bias condition A, VBE = 1.5 V dc
ICEX1
Collector to emitter
3041
cutoff current
µA dc
VCE = 60 V dc
2N6300
10
µA dc
VCE = 80 V dc
2N6301
10
ICEO
Collector to emitter
3041
Bias condition D
cutoff current
VCE = 30 V dc
2N6300
0.5
mA dc
2N6301
VCE = 40 V dc
0.5
mA dc
Bias condition D, VEB = 5 V dc
IEBO
Emitter to base cutoff current
3061
2.0
mA dc
VCE = 3 V dc; IC = 1 A dc;
hFE1
Forward-current transfer ratio
3076
500
pulsed (see 4.5.1)
VCE = 3 V dc; IC = 4 A dc;
hFE2
Forward-current transfer ratio
3076
750
18000
pulsed (see 4.5.1)
VCE = 3 V dc; IC = 8 A dc;
Forward-current transfer ratio
3076
100
hFE3
pulsed (see 4.5.1)
Test condition B; VCE = 3 V dc;
VBE(SAT)1
Base emitter voltage
3066
2.8
V dc
(nonsaturated)
Test condition A; IC = 8 A dc;
VBE(SAT)2
Base emitter voltage
3066
4.0
V dc
(saturated)
IC = 4 A dc; IB = 16 mA dc;
VCE(SAT)1
Saturation voltage;
3071
2.0
V dc
collector to emitter
pulsed (see 4.5.1)
IC = 8 A dc; IB = 80 m A dc;
VCE(SAT)2
Saturation voltage;
3071
3.0
V dc
collector to emitter
pulsed (see 4.5.1)
