MILPRF19500/539F
TABLE I. Group A inspection Continued.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 5 Continued
Test 2
VCE = 20 V dc; IC = 2.0 A dc
All device types
Test 3
VCE = 60 V dc; IC = 100 mA dc
2N6300
VCE = 80 V dc; IC = 100 mA dc
2N6301
Safe operating area
3053
Load condition B, (clamped
inductive load), TA = +25°C,
(switching)
tr + tf ≤ 1.0 µs duty cycle ≤ 10%,
tp = 1 ms (vary to obtain IC),
Rs = 0.1 ohms, RBB1 = 80 ohms,
VBB1 = 16 V dc, RBB2 = 100 ohms,
VBB2 = 1.5 V dc, VCC = 50 V dc,
IC = 8 A dc, RL ≤ 2 ohms,
L = 1 mH
2N6300
Clamp voltage = 60 V dc
2N6301
Clamp voltage = 80 V dc
Safe operating area
3053
Load condition C, (unclamped
(switching)
inductive load) (see figure 7),
TA = +25°C, duty cycle ≤ 10%,
Rs ≤ 0.1 ohms
tp = 1 ms (vary to obtain IC),
Test 1
RBB1 = 80 ohms, VBB1 ≥ 12 V dc,
RBB2 = ∞, VCC ≥ 30 V dc,
IC = 8 A dc, RL ≤ 0.5 ohms,
L = 1 mH at 8 A dc
tp = 1 ms (vary to obtain IC),
Test 2
RBB1 = 80 ohms, VBB1 ≥ 12 V dc,
RBB2 = ∞, VBB2 = 0 V dc,
VCC ≥ 30 V dc, IC = 0.2 A dc,
RL ≤ 0.5 ohms,
L = 100 mH at 0.2 A dc
Electrical measurements
See subgroup 2 of this table
Subgroups 6 and 7
Not applicable
1/
For sampling plan, see MILPRF19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroups 2 and 6.
Group E, subgroups 1 and 2.
