INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/562E
shall be completed by 26 November 2010.
26 August 2010
SUPERSEDING
MIL-PRF-19500/562D
5 November 2003
* PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, FIELD EFFECT TRANSISTOR, P-CHANNEL, SILICON,
TYPES 2N6804 AND 2N6806
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a P-channel, enhancement-mode,
MOSFET, power transistor intended for use in high density power switching applications. Four levels of product
assurance are provided for each encapsulated device type as specified in MIL-PRF-19500 and two levels of product
assurance are provided for each unencapsulated device type.
* 1.2 Physical dimensions. See figure 1, TO-204AA (formerly TO-3), figures 2, 3, and 4 for JANHC and JANKC die
dimensions.
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
Type
PT (1)
PT
VDS
VDG
VGS
ID1 (3) (4)
ID2 (3) (4)
IS
IDM
TJ and TSTG
RθJC (2)
TC = +25°C
= +25°C
TC = +25°C
TC = +100°C
(5)
TA
°C/W
°C
W
V dc
W
V dc
V dc
A dc
A dc
A dc
A(pk)
± 20
-100
-100
-55 to +150
1.67
-50
4
-11.0
75
-7.0
2N6804
-11.0
± 20
-200
-200
-55 to +150
1.67
-28
4
-6.5
75
-4.0
2N6806
-6.5
Derate linearly 0.6 W/°C for TC > +25°C.
(1)
(2)
See figure 5, thermal impedance curves.
(3)
The following formula derives the maximum theoretical ID limit. ID is also limited by package and internal
wires and may be limited by pin diameter:
TJM - TC
ID =
( RθJC ) x ( R DS ( on ) at TJM
)
(4)
See figure 6, maximum drain current graph.
IDM = 4 x ID1 as calculated in note 3.
(5)
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dscc.dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5961
