MIL-PRF-19500/563G
* TABLE I. Group A inspection - Continued.
Inspection
Limits
Symbol
Unit
1/
Method
Condition
Min
Max
Subgroup 5
Single pulse unclamped
3470
See 4.3.3, 116 devices, c = 0
inductive switching 3/
Electrical
See table I, subgroup 2
measurements
Safe operating area test
3474
See figure 7
(high voltage)
tp = 10 ms, VDS = 80 percent of
rated VDS, VDS ≤ 200 V dc max.
Electrical
See table I, subgroup 2
measurements
Subgroup 6
Not applicable
Subgroup 7
Gate charge
3471
Condition B
On-state gate charge
Qg(on)
2N6845, 2N6845U
16.3
nC
2N6847, 2N6847U
15.0
nC
Gate to source charge
Qgs
2N6845, 2N6845U
4.7
nC
2N6847, 2N6847U
3.2
nC
Gate to drain charge
Qgd
2N6845, 2N6845U
9.0
nC
2N6847, 2N6847U
8.4
nC
di/dt ≤ -100 A/µs, VDD ≤ -50 V,
Reverse recovery time
3473
trr
2N6845, 2N6845U
200
ns
IF = -4 A
2N6847, 2N6847U
300
ns
IF = -2.5 A
1/ For sampling plan, see MIL-PRF-19500.
*
2/ This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JANTXV).
Group B, subgroups 3 and 4 (JANS).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
3/ This test is optional if performed as a 100 percent screen.
