INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/565E
shall be completed by 1 February 2008.
1 November 2007
SUPERSEDING
MIL-PRF-19500/565D
30 June 2005
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, FIELD EFFECT TRANSISTOR, P-CHANNEL,
SILICON, TYPES 2N6895, 2N6896, 2N6897, AND 2N6898,
JAN, JANTX, JANTXV, AND JANS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for P-channel, enhancement-mode,
MOSFET, power transistors. Four levels of product assurance are provided for each encapsulated device type as
specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1, TO-205AF (formerly TO-39) for 2N6895, figure 2, TO-204AA for 2N6896
and 2N6897; and TO-204AE for 2N6898 (formerly TO-3).
* 1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
RθJC
VDS
VDG
VGS
ID1 (2) (3)
ID2 (2) (3)
IS
IDM
TJ and
Type
PT (1)
PT
TC =
TC =
TSTG
TC =
TA =
+25°C
+100°C
+25°C
+25°C
°C/W
°C
W
V dc
V dc
A dc
W
A dc
A dc
A(pk)
V dc
±20
2N6895
8.33
0.6
100
100
1.16
0.74
1.16
5
15.0
-55 to +150
±20
2N6896
60
4
100
100
6.0
3.8
6.0
20
2.083
-55 to +150
±20
2N6897
100
100
100
4
12
7.6
12
30
-55 to +150
1.25
2N6898
100
100
150
25
15.8
25
4
60
±20
-55 to +150
0.83
(1) Derate linearly TC > +25°C; 2N6895 (0.067 W/°C), 2N6896 (0.48 W/°C), 2N6897 (0.8 W/°C),
2N6898 (1.2 W/°C).
(2) The following formula derives the maximum theoretical ID limit. ID is limited by package and internal wires
and may be limited by pin diameter:
TJM - TC
ID = (
R θJC ) x ( R DS ( on ) at TJM )
(3) See figure 3, maximum drain current graphs.
