MIL-PRF-19500/565E
4.3 Screening (JANS, JANTX, and JANTXV levels only). Screening shall be in accordance with table E-IV of
MIL-PRF-19500 and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
Screen (see table E-IV
Measurement
of MIL-PRF-19500)
(1) (2)
JANS level
JANTX and JANTXV levels
(3)
Gate stress test (see 4.3.1)
Gate stress test (see 4.3.1)
(3)
Method 3470 of MIL-STD-750, (see 4.3.2)
Method 3470 of MIL-STD-750, (see 4.3.2)
(3) 3c
Method 3161 of MIL-STD-750, (see 4.3.3)
Method 3161 of MIL-STD-750, (see 4.3.3)
9
IGSSF1, IGSSR1, IDSS1, subgroup 2 of table I
Not applicable
herein
10
Method 1042 of MIL-STD-750, test condition B
Method 1042 of MIL-STD-750, test condition B
11
Subgroup 2 of table I herein;
Subgroup 2 of table I herein.
IGSSF1, IGSSR1, IDSS1, rDS(on)1, VGS(th)1
IGSSF1, IGSSR1, IDSS1, rDS(on)1, VGS(th)1
ΔIGSSF1 = ±20 nA dc or ±100 percent of initial
value, whichever is greater.
ΔIGSSR1 = ±20 nA dc or ±100 percent of initial
value, whichever is greater.
ΔIDSS1 = ±.2 μA dc or ±100 percent of initial
value, whichever is greater.
12
Method 1042 of MIL-STD-750, test condition A
Method 1042 of MIL-STD-750, test condition A
and test condition C. (see 4.3.4)
13
Subgroups 2 and 3 of table I herein;
Subgroup 2 of table I herein;
ΔIGSSF1 = ±20 nA dc or ±100 percent of initial
ΔIGSSF1 = ±20 nA dc or ±100 percent of initial
value, whichever is greater.
value, whichever is greater.
ΔIGSSR1 = ±20 nA dc or ±100 percent of initial
ΔIGSSR1 = ±20 nA dc or ±100 percent of initial
value, whichever is greater.
value, whichever is greater.
ΔIDSS1 = ±.2 μA dc or ±100 percent of initial
ΔIDSS1 = ±.2 μA dc or ±100 percent of initial
value, whichever is greater.
value, whichever is greater.
ΔrDS(on)1 = ±20 percent of initial value.
ΔrDS(on)1 = ±20 percent of initial value.
ΔVGS(th)1 = ±20 percent of initial value.
ΔVGS(th)1 = ±20 percent of initial value.
(1)
At the end of the test program, IGSSF1, IGSSR1, and IDSS1 are measured.
(2)
An out-of-family program to characterize IGSSF1, IGSSR1, IDSS1, and VGS(th)1 shall be invoked.
(3)
Shall be performed anytime after temperature cycling, screen 3a; and does not need to be repeated in
screening requirements.
7
