MIL-PRF-19500/565E
* TABLE I. Group A inspection - Continued.
Inspection 1/
Symbol
Limits
Unit
MIL-STD-750
Method
Conditions
Min
Max
Subgroup 2 - Continued.
gfs
Pulsed (see 4.5.1), ID = rated
3475
Forward transconductance
ID2 =(see 1.3).
2N6895
0.2
s
2N6896
1.0
s
2N6897
2.0
s
2N6898
4.0
s
Subgroup 3
TC = TJ = +125°C
High temperature operation:
3403
VDS > VGS, ID = -0.25 mA dc
Gate to source
VGS(th)2
-1.0
V dc
voltage(threshold)
±200
Gate current
3411
Bias condition C, VDS = 0 V;
IGSS2
nA dc
VGS = +20 V dc and -20 V dc
μA dc
Drain current
3413
Bias condition C, VGS = 0 V,
IDSS2
- 50
VDS = -80 V
Static drain to source on-state
3421
VGS = -10 V dc, pulsed (see 4.5.1)
rDS(on)2
resistance
Ω
2N6895
ID = - 0.74 A dc
5.66
Ω
2N6896
ID = - 3.8 A dc
0.96
Ω
2N6897
ID = - 7.6 A dc
0.465
Ω
2N6898
ID = - 15.8 A dc
0.24
TC = TJ = -55°C
Low temperature operation:
Gate to source voltage
3403
VDS > VGS, ID = -0.25 mA
VGS(th)3
-5.0
V dc
(threshold)
Subgroup 4
ID = rated ID2 (see 1.3);
3472
Switching time test
VGS = 10 V dc; Rgen =15 Ω;
RGS =15 Ω, VDD = 50 percent of
rated VDS (see 1.3)
Turn-on delay time
VDD = -50 V dc
td(on)
2N6895
ID = - 0.74 A dc
25
ns
2N6896
ID = - 3.8 A dc
60
ns
2N6897
ID = - 7.6 A dc
60
ns
2N6898
ID = - 15.8 A dc
50
ns
See footnotes at end of table.
