MIL-PRF-19500/570E
shall be completed by 26 November 2010.
26 August 2010
SUPERSEDING
MIL-PRF-19500/570D
11 January 2009
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, FIELD EFFECT,
N-CHANNEL, SILICON LOGIC-LEVEL, TYPES 2N6901 AND 2N6903,
JAN, JANTX, JANTXV, JANS, JANHC,AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for a logic-level N-channel, enhancement-
mode, MOSFET, power transistor. Four levels of product assurance are provided for each device type as specified in
MIL-PRF-19500. Two levels of product assurance are also provided for each unencapsulated device type. See 6.4
or JANHC and JANKC die versions.
* 1.2 Physical dimensions. See figure 1, TO-205AF (formerly TO-39) and figure 2 for JANHC and JANKC die
dimensions.
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
Type
VDS
VDG
VGS
IS
IDM
PT (1)
PT
ID1 (3)
ID2 (3)
TJ
RθJC
(2)
and
TC =
TA =
TC
TC
+25°C
+25°C
= +25°C
= +100°C
TSTG
°C /W
°C
W
W
V dc
V dc
V dc
A dc
A dc
A dc
A(pk)
-55 to
±10
+150
5
1.69
1.07
1.69
100
100
15.0
0.6
8.33
2N6901
±10
4
0.98
0.62
0.98
200
200
15.0
0.6
8.33
2N6903
(1) Derated linearly by 0.067 W/°C for TC > +25°C.
(2) See figure 3, thermal impedance curves.
(3) The following formula derives the maximum theoretical ID limit. ID is limited by internal construction and
may be limited by pin diameter:
TJM - TC
=
( RθJC ) x ( R DS ( on ) at TJM )
ID
