MIL-PRF-19500/570E
4.3 Screening (JANS, JANTX, and JANTXV levels only). Screening shall be in accordance with table E-IV of
MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
Screen (see, table E-IV
Measurement
of MIL-PRF-19500)
(1) (2)
JANS level
JANTX and JANTXV levels
(3)
Gate stress test (see 4.3.2)
Gate stress test (see 4.3.2)
(3)
Method 3470 of MIL-STD-750, (see 4.3.3)
Method 3470 of MIL-STD-750, (see 4.3.3)
optional
optional
(3) 3c
Method 3161 of MIL-STD-750, (see 4.3.4)
Method 3161 of MIL-STD-750, (see 4.3.4)
Not applicable
9
IGSSF1, IGSSR1, IDSS1, subgroup 2 of table I
herein
10
Method 1042 of MIL-STD-750, test
Method 1042 of MIL-STD-750, test
condition B
condition B
11
Subgroup 2 of table I herein;
Subgroup 2 of table I herein
IGSSF1, IGSSR1, IDSS1, rDS(on)1, VGS(th)1
IGSSF1, IGSSR1, IDSS1, rDS(on)1, VGS(th)1
ĆIGSSF1 = ±20 nA dc or ±100 percent of
initial value, whichever is greater.
ĆIGSSR1 = ±20 nA dc or ±100 percent of
initial value, whichever is greater.
ĆIDSS1 = ±0.2 µA dc or ±100 percent of
initial value, whichever is greater.
12
Method 1042 of MIL-STD-750, test
Method 1042 of MIL-STD-750, test
condition A, t = 240 hours
condition A or t = 48 hours minimum
at+175°C minimum.
13
Subgroups 2 and 3 of table I herein;
Subgroup 2 of table I herein;
ĆIGSSF1 = ±20 nA dc or ±100 percent of
ĆIGSSF1 = ±20 nA dc or ±100 percent of
initial value, whichever is greater.
initial value, whichever is greater.
ĆIGSSR1 = ±20 nA dc or ±100 percent of
ĆIGSSR1 = ±20 nA dc or ±100 percent of
initial value, whichever is greater.
initial value, whichever is greater.
ĆIDSS1 = ±0.2 µA dc or ±100 percent of
ĆIDSS1 = ±0.2 µA dc or ±100 percent of
initial value, whichever is greater
initial value, whichever is greater.
ĆrDS(on)1 = ±20 percent of initial value.
ĆrDS(on)1 = ±20 percent of initial value.
ĆVGS(th)1 = ±20 percent of initial value.
ĆVGS(th)1 = ±20 percent of initial value.
At the end of the test program, IGSSF1, IGSSR1, and IDSS1 are measured.
(1)
(2)
An out-of-family program to characterize IGSSF1, IGSSR1, IDSS1, and VGS(th)1 shall be invoked.
(3)
Shall be performed anytime after temperature cycling, screen 3a; and does not need to be repeated in
screening requirements.
