MIL-PRF-19500/601K
1.4 Primary electrical characteristics at TC = +25°C.
Type
Min
VGS(TH)
EAS
IAS
Max IDSS1
Max rDS(ON) (2)
VDS ≥ VGS
V(BR)DSS
at ID1
VGS = 0
VGS = 12 V dc
(1)
VGS = 0
ID = 1.0
VDS = 80
ID = 1.0
mA dc
percent of
TJ = +25°C
TJ = +150°C
mA dc
rated VDS
at ID2
at ID2
µA dc
V dc
V dc
ohm
ohm
mJ
A
Min
Max
2N7261
100
2.0
4.0
25
0.180
0.390
130
8.0
2N7262
200
2.0
4.0
25
0.350
0.840
240
5.5
(1) Unless otherwise specified, electrical characteristics, ratings, and conditions for "U" and "U5" suffix devices
(surface mount LCC) are identical to the corresponding non "U" and "U5" suffix devices.
(2) Pulsed (see 4.5.1).
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
-
Test Methods for Semiconductor Devices.
* (Copies of these documents are available online at https://assist.dla.mil/quicksearch/ or https://assist.dla.mil/ or
from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the
text of this document and the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
