The documentation process conversion
INCH POUND
measures necessary to comply with this
revision shall be completed by 28 August 1997
MIL-PRF-19500/611A
28 May 1997
SUPERSEDING
MIL-S-19500/611
30 July 1993
PERFORMANCE SPECIFICATION
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER SWITCHING
TYPES 2N7374, 2N7375, 2N7376, AND 2N7377, JANTX, JANTXV, AND JANS
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistors for use in high-speed power
switching applications. Three levels of product assurance are provided as specified in MIL-PRF-19500.
1.2 Physical dimensions. For 2N7376 and 2N7377, see figure 1 (TO-254AA), for 2N7374 and 2N7375, see figure 2 (TO-257AA).
1.3 Maximum ratings.
| RθJC
|
| PT
| PT
| VEBO
| VCBO
| VCEO
| IC
| IB
| TJ and TSTG
|
| TA = +25°C | TC = +100°C |
| Types
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
°C
| °C/W
|
| W
| W
| V dc
| V dc
| V dc
| A dc
| A dc
|
|
|
|
|
|
|
|
|
|
|
| Max
|
| 2N7374, 2N7376 | 2.5 1/
| 30 2/
| 6
| 250
| 200
| 5.0
| 1
| -65 to +200
| 3.3
|
| 2N7375, 2N7377 | 2.5 1/
| 30 2/
| 6
| 400
| 300
| 5.0
| 1
| -65 to +200
| 3.3
|
1/ Derate linearly 14.3 mW/°C above TA ≥ +25°C.
2/ Derate linearly 300 mW/°C above TC ≥ +100°C.
1.4 Primary electrical characteristics.
|
|
hFE
|
hfe
| VBE(SAT) 1/ | VCE(SAT) 1/
|
Pulse response
|
|
|
|
|
|
|
|
|
| VCE = 5.0 V dc
| VCE = 5.0 V dc | IC = 3.0 A dc
| IC = 3.0 A dc
| ton
|
toff
|
|
| IC = 1.0 A dc
| IC = 0.5 A dc
|
|
| IC = 1 A dc | IC = 1 A dc
|
|
|
| f = 10 MHz
|
|
|
|
|
|
| 2N7374 | 2N7375 |
|
|
|
| 2N7374 | 2N7375
|
|
| 2N7376 | 2N7377 |
|
|
|
| 2N7376 | 2N7377
|
| µs
| µs
| µs
|
|
|
|
| V dc
| V dc
|
| Min | 40
| 25
|
2.0
|
|
|
|
|
|
| Max | 120
| 75
|
7.0
|
1.2
|
0.4
| 0.25
| 1.5
| 2.0
|
1/ IB = 0.3 A dc for 2N7374 and 2N7376; IB = 0.6 A dc for 2N7375 and 2N7377.
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of use in improving this document
should be addressed to: Commander, Defense Supply Center Columbus, ATTN: DSCC-VAT, 3990 East Broad Street, Columbus, OH
43216-5000, by using the Standardization Document Improvement Proposal (DD Form 1426) appearing at the end of this document or
by letter.
AMSC N/A
FSC 5961
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
