MIL-PRF-19500-615 Semiconductor Device, Filed Effect Radiation Hardened Transistors, P-Channel, Silicon, Types 2N7382 And 2N7383, Jantxv M, D, R, And F And Jans M, D, R, And FThis specification covers the performance requirements for a P-channel, radiation hardened, enhancement mode, MOSFET, power transistor intended for use in high density power switching applications. Two levels of product assurance are provided for each device type as specified in MIL-PRF-19500, with avalanche energy ratings \(EAS\) and maximum avalanche current \(IAS\). See 6.5 for JANHC and JANKC die versions.
