MIL-PRF-19500/117R

TABLE II. Group E inspection qualification and requalification (all product assurance levels).

Qualification conformance

MIL-STD-750

Inspection 1/

inspection (sampling plan)

Method

Conditions

Subgroup 1

45 devices, c = 0

Temperature cycling

1051

500 cycles

Electrical measurements

See table III, steps 1, 2, 3, 4, and 5

Subgroup 2

45 devices, c = 0

Intermittent life

1037

6,000 cycles. IZ = column 8 of table IV

Electrical measurements

See table III, steps 2, 3, 4, and 5

Subgroup 4

See MIL-PRF-19500

Thermal impedance curve

Subgroups 5 and 6

Not applicable

Subgroup 9

n = 45

1057

Condition B. Cool down after solder

Resistance to glass

immersion is permitted. Test until failure

cracking

occurs on all devices with the chosen sample

or to a maximum of 25 cycles, whichever

comes first

1/ A separate sample may be pulled for each test.
