INCH-POUND
MIL-PRF-19500/156N
18 March 2008
SUPERSEDING
MIL-PRF-19500/156M
1 July 2004
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, LOW LEVEL VOLTAGE-REFERENCE
TEMPERATURE COMPENSATED, TYPES 1N935B-1, 1N937B-1, 1N938B-1, 1N939B-1,
AND 1N940B-1, 1N935BUR-1, 1N937BUR-1, 1N938BUR-1, 1N939BUR-1, AND 1N940BUR-1,
JAN, JANTX, JANTXV, AND JANS, RADIATION HARDENED (TOTAL DOSE ONLY)
TYPES JANTXVM, D, L, R, F, G, H, JANSM, D, L, R, F, G, H
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist ofthis specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for 9.0 volts ±5 percent, silicon, low bias
current, voltage-reference diodes. Four levels of product assurance are provided for each encapsulated device type
as specified in MIL-PRF-19500. Seven levels of radiation hardened (total dose only) product assurance are provided
for each encapsulated device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (DO-7 and DO-35) and figure 2 (DO-213AA).
1.3 Maximum ratings. (Unless otherwise specified TA = +25°C).
Power derating
PT
TSTG and TJ
IZM (1)
above TA = +25°C
mW/°C
°C
mA dc
mW
50
500
3.33
-65 to +175
(1) To guarantee voltage temperature stability, it is necessary to maintain an IZ of 7.5mA dc.
1.4 Primary electrical characteristics. Unless otherwise specified, primary electrical characteristics at TA = +25°C.
ΔVZ
VZ
IR
ZZ
IZ = 7.5 mA dc VR = 6.0 V
Type
(voltage - temperature
IZ = 7.5 mA dc
stability) (1)
Min
Max
μA
mV dc
ohms
volts
volts
1N935B-1, 1N935BUR-1
184
20
8.55
9.45
10.0
1N937B-1, 1N937BUR-1
37
20
8.55
9.45
10.0
1N938B-1, 1N938BUR-1
19
20
8.55
9.45
10.0
1N939B-1, 1N939BUR-1
9
20
8.55
9.45
10.0
1N940B-1, 1N940BUR-1
3.7
20
8.55
9.45
10.0
(1) To guarantee voltage temperature stability, it is necessary to maintain the proper IZ = 7.5 mA dc.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil . Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
