MIL-PRF-19500-156 Semiconductor Device, Diode, Silicon, Low Level Voltage-Reference Temperature Compensated, Types 1N935B-1, 1N937B-1, 1N938B-1, 1N939B-1, And 1N940B-1, 1N935Bur-1, 1N937Bur-1, 1N938Bur-1, 1N939Bur-1, And 1N940Bur-1, Jan, Jantx, Jantxv, And Jans, Radiation Hardened \(Total Dose Only\) Types Jantxvm, D, L, R, F, G, H, Jansm, D, L, R, F, G, HThis specification covers the performance requirements for 9.0 volts ┬▒5 percent, silicon, low bias current, voltage-reference diodes. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Seven levels of radiation hardened \(total dose only\) product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16


MIL-PRF-19500/156N
TABLE II. Group D inspection.
ΔVZ1
MIL-STD-750
JANTXV
Inspection
Unit
Symbol
JANTXV
1/ 2/
and JANS
and JANS
Pre-to post-
Pre-
Post-
irradiation
irradiation
limits
limits
M, D, L, R,
M, D, L, R,
irradiation
Method
Conditions
F, G, and H
F, G, and H
change
Min
Max
Min
Max
Min
Max
Subgroup 1
Not applicable
Subgroup 2
IZ = 7.5
Steady-state total
1019
dose irradiation
±0.01 mA dc,
condition A
IZ = 7.5
VZ
8.55
9.45
8.55
9.45
V dc
Reference voltage
4022
(see 4.5.3)
±0.01 mA dc
ZZ
IZ = 7.5
20
20
ohms
Small-signal
4051
breakdown
±0.01 mA dc
impedance
μA dc
IR
Reverse current
4016
DC method,
10.0
10.0
VR = 6.0 V dc
leakage
ΔVZ
IZ = 7.5
4022
Voltage stability
(see 4.5.1)
±0.01 mA dc,
TA = +25°C ±2°C
±4.0
1N935B-1,
mV
1N935BUR-1
±3.5
1N937B-1,
mV
1N937BUR-1
±3.0
1N938B-1,
mV
1N938BUR-1
±2.5
1N939B-1,
mV
1N939BUR-1
±1.5
1N940B-1,
mV
1N940BUR-1
1/ For sampling plan, see MIL-PRF-19500.
2/ Group D qualification may be performed anytime prior to lot formation.
9
