MIL-PRF-19500/156N

5. PACKAGING

5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order

(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel

need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are

maintained by the Inventory Control Point's packaging activities within the Military Service or Defense Agency, or

within the Military Service's system commands. Packaging data retrieval is available from the managing Military

Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible

packaging activity.

6. NOTES

(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.

The notes specified in MIL-PRF-19500 are applicable to this specification.)

6.1 Intended use. Semiconductors conforming to this specification are intended for original equipment design

applications and logistic support of existing equipment.

6.2 Acquisition requirements. Acquisition documents should specify the following:

a. Title, number, and date of this specification.

b. Packaging requirements (see 5.1).

c. Lead finish (see 3.4.1).

d. Product assurance level and type designator.

6.3 Qualification. With respect to products requiring qualification, awards will be made only for products which are,

at the time of award of contract, qualified for inclusion in Qualified Manufacturers List (QML 19500) whether or not

such products have actually been so listed by that date. The attention of the contractors is called to these

requirements, and manufacturers are urged to arrange to have the products that they propose to offer to the Federal

Government tested for qualification in order that they may be eligible to be awarded contracts or orders for the

products covered by this specification. Information pertaining to qualification of products may be obtained from

Defense Supply Center, Columbus, ATTN: DSCC/VQE, P.O. Box 3990, Columbus, OH 43216-5000 or e-mail

6.4 Substitution of radiation hardened devices. See MIL-PRF-19500.

* 6.5 Substitutability of dash one parts. Non-dash-one devices have been deleted from this specification. Dash-one

devices are a direct substitute for non dash-one devices and are preferred. The following table shows the direct

substitutability.

Superseded

Superseding

1N935B

1N935B-1

1N937B

1N937B-1

1N938B

1N938B-1

1N939B

1N939B-1

1N940B

1N940B-1

6.6 Substitution of ΔVZ devices. Device types within this series with higher type numbers (lower ΔVZ) are a direct

one-way substitution for lower type numbers (higher ΔVZ).
