MIL-PRF-19500/255Y
*
4.4.3.2 Group C inspection (JAN, JANTX, and JANTXV), table E-VII of MIL-PRF-19500.
Subgroup
Method
Condition
*
C2
2036
Test condition E; not applicable for UA, UB, UBC, UBN, and UBCN devices.
RθJA and RθJC only, as applicable (see 1.3 and 4.3.3) and in accordance with thermal
C5
3131
impedance curves.
C6
Not applicable.
4.4.3.3 Group C sample selection. Samples for subgroups in group C shall be chosen at random from any
inspection lot containing the intended package type and lead finish procured to the same specification which is
submitted to and passes table I tests herein for conformance inspection. When the final lead finish is solder or any
plating prone to oxidation at high temperature, the samples for C6 life test may be pulled prior to the application of
final lead finish. Testing of a subgroup using a single device type enclosed in the intended package type shall be
considered as complying with the requirements for that subgroup.
* 4.4.4 Group D inspection. Conformance inspection for hardness assured JANS and JANTXV types shall include
the group D tests specified in table II herein. These tests shall be performed as required in accordance with
MIL-PRF-19500 and method 1019 of MIL-STD-750, for total ionizing dose or method 1017 of MIL-STD-750 for
neutron fluence as applicable (see 6.2 herein), except group D, subgroup 2 may be performed separate from other
subgroups. Alternate package options may also be substituted for the testing provided there is no adverse effect to
the fluence profile.
4.4.5 Group E inspection. Group E inspection shall be conducted in accordance with the conditions specified for
subgroup testing in table E-IX of MIL-PRF-19500 and as specified in table III herein. Electrical measurements (end-
points) shall be in accordance with table I, subgroup 2 herein; delta measurements shall be in accordance with the
applicable steps of 4.5.3.
4.5 Method of inspection. Methods of inspection shall be as specified in the appropriate tables and as follows.
4.5.1 Pulse measurements. Conditions for pulse measurement shall be as specified in section 4 of MIL-STD-750.
4.5.2 Input capacitance. This test shall be conducted in accordance with method 3240 of MIL-STD-750, except
the output capacitor shall be omitted.
4.5.3 Delta requirements. Delta requirements shall be as specified below:
Step
Inspection
MIL-STD-750
Symbol
Limit
Unit
Method
Conditions
ĆICB02
1
Collector-base cutoff
3036
Bias condition D,
100 percent of initial
VCB = 60 V dc
current
value or 8 nA dc,
(1)
whichever is greater.
ĆhFE4
±25 percent change
2
Forward current
3076
VCE = 10 V dc;
transfer ratio
IC = 150 mA dc;
(1)
from initial reading.
pulsed, see 4.5.1
(1) Devices which exceed the table I limits herein for this test shall not be accepted.
