INCH-POUND
The documentation and process conversion measures
necessary to comply with this document shall be
MIL-PRF-19500/260L
completed by 26 April 2010.
26 January 2010
SUPERSEDING
MIL-PRF-19500/260K
14 March 2007
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, POWER RECTIFIER,
TYPES 1N1202A, 1N1204A, 1N1206A, 1N3671A, 1N3673A, AND AR VERSIONS,
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC,
1N1124A, 1N1126A, 1N1128A, 1N3649, 1N3650, 1N1124RA,
1N1126RA, 1N1128RA, 1N3649R, AND 1N3650R, JAN ONLY
The 1N1124A, 1N1126A, 1N1128A, 1N3649, 1N3650 and reverse versions have been
moved from MIL-S-19500/104, which has been canceled, are now inactive for new design.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon semiconductor power rectifier
diodes. Four levels of product assurance are provided for each encapsulated 1N1202A, 1N1204A, 1N1206A,
1N3671A, 1N3673A device type as specified in MIL-PRF-19500, and two levels of product assurance for each
unencapsulated device type. One level of product assurance is provided for each device type as specified in
MIL-PRF-19500, for the 1N1124A, 1N1126A, 1N1128A, 1N3649, 1N3650. For normal and reverse (A, R, RA, and AR
suffix) type devices see 3.4.1.
1.2 Physical dimensions. See figure 1 (DO-203AA, formerly DO4) and figure 2 (JANHC and JANKC).
1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
IO
If(surge)
Barometric
TC = 150°C
TC = 150°C
Type
VRWM
pressure
TJ and TSTG
RθJC
(reduced)
T = 1/120 s
°
°C/W max
A dc
A pk
mmHg
V dc
C
1N1202A
200
12
(1)
240
N/A
-65 to +200
2.0
1N1204A
400
12
(1)
240
8
-65 to +200
2.0
1N1206A
600
12
(1)
240
16
-65 to +200
2.0
1N3671A
800
12
(1)
240
30
-65 to +200
2.0
1N3673A
1000
12
(1)
240
54
-65 to +200
2.0
1N1124A
(2)
200
3.3
(3)
25
8
-65 to +175
2.0
1N1126A
(2)
400
3.3
(3)
25
8
-65 to +175
1N1128A
(2)
600
3.3
(3)
25
16
-65 to +175
2.0
1N3649
(2)
800
3.3
(3)
25
30
-65 to +175
2.0
1N3650
(2)
1,000
3.3
(3)
25
54
-65 to +175
2.0
See notes on next page.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of this
address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
