MIL-PRF-19500/260L
4.3 Screening. Screening shall be in accordance with appendix E, table E-IV of MIL-PRF-19500, and as specified
herein. The following measurements shall be made in accordance with table I herein. Devices that exceed the limits
of table I herein shall not be acceptable.
Screen (see appendix
Measurement
E, table E-IV of
MIL-PRF-19500)
JANS level
JANTX and JANTXV levels
1a
Required
Not required
1b
Required
Required (JANTXV only)
2
Optional
Not required
3a
Required
Required
(1) 3b
Surge (see 4.3.1)
Surge (see 4.3.1)
3c
Thermal impedance (see 4.3.2)
Thermal impedance (see 4.3.2)
4
Not applicable
Not applicable
5
Applicable
Not applicable
6
Not applicable
Not applicable
7a
Optional
Optional
7b
Optional
Optional
8
Required
Not required
(2) 9
VF1 and IR1
Not applicable
10
Method 1038 of MIL-STD-750,
Not applicable
test condition A, t = 96 hours
11
VF1 and IR1; subgroup 2 of table I
VF1 and IR1
herein, ĆVF1 = ±0.1 V(pk) from
initial value; ĆIR1 = ±5 µA dc or 100
percent from the initial value,
whichever is greater.
12
Burn-in, see 4.3.3 and 4.5.2.
Method 1038 of MIL-STD-750
method 1038 of MIL-STD-750, test
test condition A, t = 48 hours
condition B.
13
Subgroups 2 and 3 of table I
Subgroup 2 of table I herein,
herein; ĆVF1 = ±0.1 V (PK); ĆIR1 =
ĆVF1 = ±0.1 V(pk) from initial value;
ĆIR1 = ±5.0 µA dc or 100 percent from
±5 µA dc or 100 percent from the
initial value, whichever is greater.
the initial value, whichever is greater.
14a
Required
Required
14b
Required
Required
15
Required
Not required
16
Required
Not required
(1) Surge shall precede thermal impedance. These tests shall be performed anytime after screen 3a and
before screen 9.
(2) IR1 measurement shall not be indicative of an open condition.
4.3.1 Surge current. Surge current, method 4066 of MIL-STD-750. IO = 0; VRM(W) = 0; IFSM = 275 A; six surges;
TA = 25°C; tp = 8.3 ms; one minute minimum time between surges.
NOTE: A shorter time between surges will be allowed as long as it can be demonstrated that ĆTJ ≤ 10°C, as
measured immediately prior to the first current pulse and immediately after the final current pulse.
