MIL-PRF-19500-260 Semiconductor Device, Diode, Silicon, Power Rectifier, Types 1N1202A, 1N1204A, 1N1206A, 1N3671A, 1N3673A, And Ar Versions, Jan, Jantx, Jantxv, Jans, Janhc, And Jankc, 1N1124A, 1N1126A, 1N1128A, 1N3649, 1N3650, 1N1124Ra, 1N1126Ra, 1N1128Ra , 1N3649R, And 1N3650R, Jan OnlyThis specification covers the performance requirements for silicon semiconductor power rectifier diodes. Four levels of product assurance are provided for each encapsulated 1N1202A, 1N1204A, 1N1206A, 1N3671A, 1N3673A device type as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type. One level of product assurance is provided for each device type as specified in MIL-PRF-19500, for the 1N1124A, 1N1126A, 1N1128A, 1N3649, 1N3650. For normal and reverse \(A, R, RA, and AR suffix\) type devices see 3.4.1.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/260L
Ltr
Dimensions
Notes
Inches
Millimeters
Min
Max
Min
Max
NOTES:
CH
.405
10.29
1. Dimensions are in inches.
2. Millimeters are given for general information only.
CD
.424
10.77
3. Units must not be damaged by torque of 15 inch-
pounds applied to 10-32NF-2B nut assembled on
HF
.424
.437
10.77
11.10
thread.
4. Diameter of unthreaded portion .189 inch (4.80 mm)
HT
.075
.175
1.90
4.44
max and .163 inch (4.14 mm) min.
5. Complete threads to extend to within 2.5 threads of
OAH
.800
20.32
seating plane.
6. Angular orientation of this terminal is undefined.
C
.250
6.35
9
7. Max pitch diameter of plated threads shall be basic
pitch diameter .169 inch (4.31 mm) reference
φT
.060
1.52
FED-STD-H28 (Screw Thread Standards for Federal
Services.)
SL
.422
.453
10.72
11.51
8. The A.S.A. thread reference is 10-32UNF2A.
9. Terminal shape is unrestricted.
K
3,5,7
10. Reversed (anode to stud) units shall be marked with
an R following the last digit in the type number
11. In accordance with ASME Y14.5M, diameters are
equivalent to φx symbology.
FIGURE 1. Physical dimensions (DO-203AA, formerly DO-4), 1N1202A, 1N1204A, 1N1206A,
1N3671A, 1N3673A and AR versions, and 1N1124A, 1N1126A, 1N1128A,
and RA versions 1N3649, 1N3650, and R versions.
3
