MIL-PRF-19500-286 Semiconductor Device, Diode, Silicon, Power Rectifier, Types 1N4245 Through 1N4249, Jan, Jantx, Jantxv, And JanhcThis specification covers the performance requirements for silicon, power rectifier, medium-recovery diodes. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/286K
50
Design Curve
10
5
1
50
1
10
0.01
0.1
0.001
He atin g Time (se c)
FIGURE 3. Thermal impedance graph RθJL 36°C/W.
