MIL-PRF-19500/313J
TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 2 - Continued
Collector to base cutoff current
3036
Bias condition D
ICBO2
2N2432, 2N2432UB
10
nA dc
VCE = 25 V dc
2N2432A, 2N2432AUB
10
nA dc
VCE = 40 V dc
Collector to emitter cutoff
3041
Bias condition C
ICES1
current
2N2432, 2N2432UB
10
nA dc
VCB = 25 V dc
2N2432A, 2N2432AUB
10
nA dc
VCB = 40 V dc
Emitter to collector cutoff
3041
2
nA dc
IECS1
Bias condition C; VEC = 15 V dc;
current
VBC = 0; (see 4.5.2)
Emitter to base cutoff current
3061
2
nA dc
Bias condition D; VEB = 15 V dc
IEBO
VCE = 5 V dc; IC = 10 µA dc
Forward-current transfer ratio
3076
30
hFE1
Forward-current transfer ratio
3076
80
400
VCE = 5 V dc; IC = 1 mA dc
hFE2
Forward-current transfer ratio
3076
VCE = 5 V dc; IE = 0.2 mA dc;
hFE(inv)1
(inverted connection)
(see 1.4 and 4.5.4)
2N2432, 2N2432UB
2
2N2432A, 2N2432AUB
3
Saturation voltage and
3071
0.15
V dc
IC = 10 mA dc; IB = 0.5 mA dc
VCE(sat)
resistance
See 1.4.
IB = 200 µA dc; IE = 0 mA dc
Emitter to collector offset
VEC(ofs)1
voltage
(see 4.5.5 and figure 9)
2N2432, 2N2432UB
0.5
mV dc
2N2432A, 2N2432AUB
0.4
mV dc
Emitter to collector offset
IB = 1 mA dc; IE = 0 mA dc
VEC(ofs)2
voltage
(see 4.5.5 and figure 9)
2N2432, 2N2432UB
1.0
mV dc
2N2432A, 2N2432AUB
0.7
mV dc
Subgroup 3
TA = +125°C
High-temperature operation:
Collector to emitter cutoff
3041
Bias condition C
ICES2
current
2N2432, 2N2432UB
250
nA dc
VCE = 25 V dc
2N2432A, 2N2432AUB
250
nA dc
VCE = 40 V dc
