MIL-PRF-19500-356 Semiconductor Device, Diode, Silicon, Voltage Regulator, Types 1N4954 Through 1N4996, 1N5968, 1N5969,And 1N6632 Through 1N6637, 1N4954Us Through 1N4996Us, 1N5968Us, 1N5969Us, And 1N6632Us Through 1N6637Us, And C And D Tolerance Suffix Devices, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for silicon, voltage regulator diodes. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type die.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/356L

Dimensions

Inches

Millimeters

Ltr

Notes

Min

Max

Min

Max

.090

.145

2.29

3.68

.130

.300

3.30

7.62

.037

.043

0.94

1.09

1.00

1.300

25.40

33.02

.050

1.27

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Package contour optional with BD and length BL. Heat slugs, if any, shall be included within this

cylinder length but shall not be subject to minimum limit of BD.

4. The specified lead diameters apply in the zone between .050 inch (1.27 mm) from the diode body

and the end of the lead.

5. In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.

FIGURE 1. Physical dimensions, non-surface mount devices.
