MIL-PRF-19500/357M
completed by 6 August 2013.
6 May 2013
SUPERSEDING
MIL-PRF-19500/357L
17 July 2010
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, AMPLIFIER,
TYPES 2N3634 THROUGH 2N3637, 2N3634UB THROUGH 2N3637UB, 2N3634UBN THROUGH 2N3637UBN,
2N3634L THROUGH 2N3637L, JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF,
JANSG, JANSH, JANHCA, JANKCA, JANKCAM, JANKCAD, JANKCAP, JANKCAL, JANKCAR, JANKCAF,
JANKCAG, JANKCAH, JANHCB, JANKCB, JANKCBM, JANKCBD, JANKCBP, JANKCBL,
JANKCBR, JANKCBF, JANKCBG, AND JANKCBH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, low-power amplifier, and
switching transistors. Four levels of product assurance are provided for each encapsulated device type as specified
in MIL-PRF-19500 and two levels of product assurance are provided for unencapsulated devices. RHA level
designators "M", "D", "P", "L", "R", "F', "G", and "H" are appended to the device prefix to identify devices, which have
passed RHA requirements.
* 1.2 Physical dimensions. See figure 1 (TO-5 and TO-39), figure 2 (UB and UBN), and figures 3 and 4 (JANHC
and JANKC).
1.3 Maximum ratings. Unless otherwise specified TA = +25°C.
*
PT (1)
PT (2)
PT (3)
IC
TJ and
VCBO
VCEO
VEBO
RθJA
RθJC
RθJSP
Types
TSTG
TA =
TC =
TSP =
(4)
(4)
(4)
+25°C
+25°C
+25°C
°C/W
°C/W
°C/W
°C
W
W
W
A dc
V dc
V dc
V dc
2N3634, 2N3634L
1
5
N/A
1
140
140
5
175
35
N/A
-65 to
2N3634UB and UBN
0.5
N/A
1.5
1
140
140
5
325
N/A
90
+200
2N3635, 2N3635L
1
5
N/A
1
140
140
5
175
35
N/A
1
5
2N3635UB and UBN
0.5
N/A
1.5
140
140
325
N/A
90
1
5
2N3636, 2N3636L
1
5
N/A
175
175
175
35
N/A
1
5
2N3636UB and UBN
0.5
N/A
1.5
175
175
325
N/A
90
1
5
2N3637, 2N3637L
1
5
N/A
175
175
175
35
N/A
2N3637UB and UBN
0.5
N/A
1.5
1
175
175
5
325
N/A
90
*
(1)
See figure 5 and 6.
*
(2)
See figure 7.
See figure 8.
*
(3)
*
(4)
See figures 9, 10, and 11.
