MIL-PRF-19500/357M
4.4.5 Group E inspection. Group E inspection shall be conducted in accordance with the conditions specified for
subgroup testing in appendix E, table E-IX of MIL-PRF-19500 and as specified herein. Electrical measurements
(end-points) shall be in accordance with subgroup 2 of table I and 4.5.4 herein.
4.5 Method of inspection. Methods of inspection shall be as specified in the appropriate tables and as follows.
4.5.1 Pulse measurements. Conditions for pulse measurement shall be as specified in section 4 of
MIL-STD-750.
4.5.2 Input capacitance. This test shall be conducted in accordance with method 3240 of MIL-STD-750, except
the output capacitor shall be omitted.
4.5.3 Noise figure. Noise figure shall be measured using a model 310B Quan Tech Laboratories test set, or
equivalent. Conditions shall be as specified in table I herein.
4.5.4 Delta requirements. Delta requirements shall be as specified below:
Step
Inspection
MIL-STD-750
Symbol
Limit
Unit
Method
Conditions
ĆICB02
1
Collector-base cutoff
3036
Bias condition D,
100 percent of initial
value or ±20 nA dc,
current
VCB = 100 V dc
(1)
whichever is greater.
ĆhFE5
±25 percent change
2
Forward current
3076
VCE = 10 V dc;
transfer ratio
IC = 150 mA dc;
(1)
from initial reading.
pulsed see 4.5.1
(1) Devices which exceed the table I limits for this test shall not be accepted.
12
