MIL-PRF-19500/382J

4.3 Screening (JANS, JANTX, and JANTXV levels only). Screening shall be in accordance with table E-IV of

MIL-PRF-19500 and as specified herein. The following measurements shall be made in accordance with table I

herein. Devices that exceed the limits of table I herein shall not be acceptable.

Screen (see table E-IV

Measurement

of MIL-PRF-19500)

JANS

JANTX and JANTXV

(1) 3c

Required, method 3131 of MIL-STD-750.

Required, method 3131 of

MIL-STD-750. (see 4.3.3)

Not applicable

ICBO1 and hFE (inv)1

ICBO1; hFE (inv)1 ;

ICBO1 and hFE (inv)1

ĆICBO1 = 100 percent of initial value or

0.2 nA dc for 2N2944 and 2N2945,

0.5 nA dc for 2N2946

ĆhFE (inv)1 = 25 percent of initial value.

Subgroups 2 and 3 of table I herein;

Subgroups 2 of table I herein;

ĆICBO1 = 100 percent of initial value or

0.2 nA dc for 2N2944A, 2N2945A,

0.2 nA dc for 2N2944 and 2N2945,

2N2945AM, 2N2945AUB, and 2N2945AUBM.

0.5 nA dc for 2N2946;

ĆhFE (inv)1 = 25 percent of initial value.

0.5 nA dc for 2N2946A;

ĆhFE (inv)1 = 25 percent of initial value.

(1) Shall be performed any time after temperature cycling, screen 3a; JANTX and JANTXV levels do not need to

be repeated in screening requirements.

4.3.1 Screening (JANHC and JANKC). Screening for JANHC and JANKC die shall be in accordance with

MIL-PRF-19500 "Discrete Semiconductor Die/Chip Lot Acceptance". Burn-in duration for the JANKC level follows

JANS requirements; the JANHC follows JANTX requirements.

4.3.2 Power burn-in conditions. Power burn-in conditions are as follows: VCB = 10 to 30 V dc. Power shall be

applied to achieve TJ = +135�C minimum using a minimum PD = 75 percent of PT maximum rated as defined in 1.3.

With approval of the qualifying activity and preparing activity, alternate burn-in criteria (hours, bias conditions, TJ, and

mounting conditions) may be used for JANTX and JANTXV quality levels. A justification demonstrating equivalence

is required. In addition, the manufacturing site's burn-in data and performance history will be essential criteria for

burn-in modification approval. Use method 3100 of MIL-STD-750 to measure TJ.

4.3.3 Thermal impedance. The thermal impedance measurements shall be performed in accordance with

method 3131 of MIL-STD-750 using the guidelines in that method for determining IM, IH, tH, tMD, (and VC where

appropriate).
