INCH-POUND
The documentation and process conversion
measures necessary to comply with this document
MIL-PRF-19500/392J
shall be completed by 26 November 2011.
26 August 2011
SUPERSEDING
MIL-PRF-19500/392H
31 July 2006
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, SWITCHING,
TYPES 2N3485A AND 2N3486A, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP silicon switching transistors. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (TO-46).
1.3 Maximum ratings, unless otherwise specified, TC =+ 25°C.
PT
PT
VCBO
VCEO
VEBO
IC
TJ and TSTG
RθJC
RθJA
TA =+25°C
TC = +25°C
(1) (2)
(1) (2)
°C/W
°C
°C/W
W
V dc
V dc
mA dc
V dc
W
0.5
2.0
60
60
5
600
80
325
-65 TO +200
(1) For derate see figures 2 and 3.
(2) For thermal impedance see figures 4 and 5.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since
contact information can change, you may want to verify the currency of this address information using the
ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 5961
