MIL-PRF-19500/392J

* TABLE II. Group E inspection (all quality levels) - for qualification or re-qualification only.

Inspection

MIL-STD-750

Qualification

Method

Conditions

Subgroup 1

45 devices

c=0

1051

Test condition C, 500 cycles.

Temperature cycling

(air to air)

Hermetic seal

Fine leak

1071

Gross leak

Electrical measurements

See table I, subgroup 2 and 4.5.2 herein.

Subgroup 2

45 devices

c=0

1037

Intermittent life

Intermittent operation life : VCB = 10 V dc, 6,000 cycles.

Adjust device current, or power, to achieve a minimum

ĆTJ of +100�C.

Electrical measurements

See table I, subgroup 2 and 4.5.2 herein.

Subgroup 4

Thermal impedance curves

See table E-IX of MIL-PRF-19500, group E, subgroup 4.

Sample size

N/A

Subgroup 5

Not applicable

Subgroup 6

11 devices

ESD

1020

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
