MIL-PRF-19500-426 Semiconductor Device, Transistor, Pnp, Silicon, Amplifier Type 2N4957 And 2N4957Ub, Jan, Jantx, Jantxv, Jantxvm, Jantxvd, Jantxvp, Jantxvl, Jantxvr, Jantxvf, Jantxvg, Jantxvh, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhc, Janhcm, Janhcd, Janhcp, Janhcl, Janhcr, Janhcf, Janhcg, Janhch, Jankc, Jankcm, Jankcd, Jankcp, Jankcl, Jankcr, Jankcf, Jankcg, ...This specification covers the performance requirements for PNP silicon, VHF-UHF amplifier transistors. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type. Radiation hardness assurance \(RHA\) level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

INCH-POUND

The documentation and process conversion

measures necessary to comply with this revision

MIL-PRF-19500/426H

shall be completed by 6 August 2014.

6 May 2014

SUPERSEDING

MIL-PRF-19500/426G

30 March 2013

PERFORMANCE SPECIFICATION SHEET

SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, AMPLIFIER

TYPE 2N4957 AND 2N4957UB, JAN, JANTX, JANTXV, JANTXVM, JANTXVD, JANTXVP, JANTXVL, JANTXVR,

JANTXVF, JANTXVG, JANTXVH, JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH,

JANHC, JANHCM, JANHCD, JANHCP, JANHCL, JANHCR, JANHCF, JANHCG, JANHCH, JANKC, JANKCM,

JANKCD, JANKCP, JANKCL, JANKCR, JANKCF, JANKCG, AND JANKCH

This specification is approved for use by all Departments

and Agencies of the Department of Defense.

The requirements for acquiring the product described herein shall consist of

this specification sheet and MIL-PRF-19500.

1. SCOPE

1.1 Scope. This specification covers the performance requirements for PNP silicon, VHF-UHF amplifier

transistors. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two

levels of product assurance are provided for each unencapsulated device type. Radiation hardness assurance (RHA)

level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices which

have passed RHA requirements.

1.2 Physical dimensions. See figure 1 (TO-72) and figure 2 (surface mount) and figure 3 (JANHC and JANKC die).

* 1.3 Maximum ratings.

PT (1)

VCEO

VCBO

VEBO

TSTG and TJ

TA = +25�C

�C

V dc

mA dc

V dc

200

-30

-3.0

-65 to +200

(1) Derate at 1.14 mW/�C above TA > +25�C.

Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime, ATTN:

VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact

information can change, you may want to verify the currency of this address information using the ASSIST Online

AMSC N/A

FSC 5961
