MIL-PRF-19500-426 Semiconductor Device, Transistor, Pnp, Silicon, Amplifier Type 2N4957 And 2N4957Ub, Jan, Jantx, Jantxv, Jantxvm, Jantxvd, Jantxvp, Jantxvl, Jantxvr, Jantxvf, Jantxvg, Jantxvh, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh, Janhc, Janhcm, Janhcd, Janhcp, Janhcl, Janhcr, Janhcf, Janhcg, Janhch, Jankc, Jankcm, Jankcd, Jankcp, Jankcl, Jankcr, Jankcf, Jankcg, ...This specification covers the performance requirements for PNP silicon, VHF-UHF amplifier transistors. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type. Radiation hardness assurance \(RHA\) level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/426H

1.4 Primary electrical characteristics (common to all types).

Limits

|hfe|

rb'Cc

Ccb

Gpe

hFE3

VCE = -10

IE = -2.0 mA

IE = -2.0 mA dc

VCB = -10 V dc

IC = -2.0 mA dc

IE = 0

V dc

f = 63.6 MHz

f = 450 MHz

dc, VCE = -10

VCE = -10 V dc

100 kHz ≤ f ≤ 1

IC = -5.0

VCB = -10 V dc

VCE = -10 V dc

V dc

f = 450 MHz

MHz

f = 100 MHz

mA dc

(2N4957 only)

(2N4957UB

only)

Min

1.0

Max

165

8.0

16.0

0.8

3.5

2. APPLICABLE DOCUMENTS

* 2.1 General. The documents listed in this section are specified in sections 3 or 4 of this specification. This section

does not include documents cited in other sections of this specification or recommended for additional information or

as examples. While every effort has been made to ensure the completeness of this list, document users are

cautioned that they must meet all specified requirements of documents cited in sections 3 or 4 of this specification,

whether or not they are listed.

2.2 Government documents.

2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those cited in the solicitation or contract.

DEPARTMENT OF DEFENSE SPECIFICATIONS

MIL-PRF-19500

Semiconductor Devices, General Specification for.

DEPARTMENT OF DEFENSE STANDARDS

MIL-STD-750

Test Methods for Semiconductor Devices.

* (Copies of these documents are available online at https://quicksearch.dla.mil/).

2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the

text of this document and the references cited herein, the text of this document takes precedence. Nothing in this

document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.

3. REQUIREMENTS

3.1 General. The individual item requirements shall be as specified in MIL-PRF-19500 and as modified herein.

3.2 Qualification. Devices furnished under this specification shall be products that are manufactured by a

manufacturer authorized by the qualifying activity for listing on the applicable qualified manufacturer's list (QML)

before contract award (see 4.2 and 6.3).

3.3 Abbreviations, symbols, and definitions. Abbreviations, symbols, and definitions used herein shall be as

specified in MIL-PRF-19500.
