MIL-PRF-19500/426H

4.3 Screening (JANTX, JANTXV and JANS levels only). Screening shall be in accordance with table E-IV of

MIL-PRF-19500 and as specified herein. The following measurements shall be made in accordance with table I

herein. Devices that exceed the limits of table I herein shall not be acceptable.

Screen (see table IV

Measurement

JANS level

JANTX and JANTXV levels

Thermal impedance, method 3131 of

MIL-STD-750 (see 4.3.3)

Not applicable

ICBO1, hFE3

24 hours minimum

ICBO1; hFE3;

ICBO1 ,hFE3

ĆICBO1 = 100 percent of initial value

or -10 nA dc, whichever is greater.

ĆhFE3 = �20 percent

See 4.3.1, 240 hours minimum

See 4.3.1, 80 hours minimum

Subgroups 2 and 3 of table I herein;

Subgroup 2 of table I herein;

ĆICBO1= 100 percent of initial value

ĆICBO1= 100 percent of initial value or

or -10 nA dc, whichever is greater;

-10 nA dc, whichever is greater;

ĆhFE3 = �20 percent

* 4.3.1 Power burn-in. Power burn-in conditions are as follows: TA = room ambient as defined in the general

requirements of 4.5 of MIL-STD-750, VCB = -10 - -20 V dc. A power dissipation of PD = 100 percent of PT maximum

as defined in 1.3 shall be used.

4.3.2 Screening (JANHC and JANKC). Screening of JANHC and JANKC die shall be in accordance with

MIL-PRF-19500, "Discrete Semiconductor Die/Chip Lot Acceptance". Burn-in duration for the JANKC level follows

JANS requirements; the JANHC follows JANTX requirements.

4.3.3 Thermal impedance (ĆVBE measurements). The ĆVBE measurements shall be performed in accordance with

method 3131 of MIL-STD-750 using the guidelines in that method for determining VH, VCE, IM, IH, tH, and tMD. The

ĆVBE limit used in screen 3c and table I, subgroup 2 shall be set statistically by the supplier over several die lots and

submitted to the qualifying activity for approval.
