The documentation and process
INCH-POUND
conversion measures necessary to
MIL-PRF-19500/445D
comply with this revision shall be
18 June 1999
completed by 18 September 1999.
SUPERSEDING
MIL-S-19500/445C
4 January 1994
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, SWITCHING
TYPES 1N5712, 1N5712-1, AND 1N5712UR-1
JAN, JANTX, JANTXV, JANJ, JANS, JANHC AND JANKC
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for Schottky barrier diodes. Five levels of product assurance are
provided for each encapsulated device type as specified in MIL-PRF-19500. Two level of product assurance are provided for each
unencapsulated device type.
1.2 Physical dimensions. See figure 1, similar to D0-35 (1N5712 and 1N5712-1), figure 2 (DO-213AA), and figure 3 (JANHC and
JANKC).
1.3 Maximum ratings.
Type
VRWM
IO
TSTG and TJ
RθJL 1/
°C/W
°C
mA dc
V(pk)
1N5712
16
33 2/
700
-65 to +200
1N5712-1
16
33 3/
250
-65 to +150
1N5712UR-1
16
33 4/
100
-65 to +150
1/
Lead length = .375 inch except for surface mount.
At TL = +140°C and L = .375 inch, derate IO to 0 at +200°C.
2/
At TL = +130°C and L = .375 inch, derate IO to 0 at +150°C.
3/
At TEC = +140°C, derate IO to 0 at +150°C.
4/
1.4 Primary electrical characteristics.
C
τCL
V(BR)1
VF1
VF2
IR
ZθJX
Limits
VR = 0, f = 1 MHz
IR
IF
IF
IF
VR
Vsig = 50 mV(pk)
= 10 µA dc
= 1 mA
= 20.0
= 35 mA
= 16 V dc
dc
mA
dc
°C/W
pF
V dc
nA dc
ps
V dc
V dc
1N5712
1N5712-1
1N5712
1N5712-1
1N5712UR-1
1N5712UR-1
Minimum
20
0.41
1.0
150
100
Maximum
1.2
2.0
100
40
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be of use in improving this document
should be addressed to: Commander, Defense Supply Center Columbus, ATTN: DSCC-VAT, 3990 East Broad St., Columbus, OH
43216-5000, by using the addressed Standardization Document Improvement Proposal (DD Form 1426) appearing at the end of this
document or by letter.
AMSC N/A
FSC 5961
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
