MIL-PRF-19500/445D
4.5.4 Decap internal visual scribe and break. Scratch glass at cavity area with diamond scribe. Carefully snap open. Using 30X
magnification examine the area where die (or bonding material) are in contact with the plugs, verify metallurgical bonding area.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order (see 6.2). When
actual packaging of material is to be performed by DoD personnel, these personnel need to contact the responsible packaging activity to
ascertain requisite packaging requirements. Packaging requirements are maintained by the Inventory Control Points' packaging activity
within the Military Department or Defense Agency, or within the Military Departments' System Command. Packaging data retrieval is
available from the managing Military Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting
the responsible packaging activity.
5.2 Marking. Unless otherwise specified (see 6.2), marking shall be in accordance with MIL-STD-129.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.)
6.1 Notes. The notes specified in MIL-PRF-19500 are applicable to this specification.
6.2 Acquisition requirements. Acquisition documents should specify the following:
a.
Issue of DODISS to be cited in the solicitation.
b.
Lead finish as specified (see 3.3.1).
c.
Product assurance level, type designator, and for die acquisition, the JANHC and JANKC identification (see figure 3 and 6.3).
6.3 Suppliers of die. The qualified die suppliers with the applicable letter version (example JANHCA1N5712) will be identified on the
QPL.
JANC ordering information
Manufacturer
PIN
55801
1N5712
JANHCA1N5712
1N5712
JANKCA1N5712
6.4 Interchangeability information. The -1 device is not electrically identical to the non -1 device due to a difference in capacitance.
Applications may be affected and users should evaluate their particularly applications for interchangeability.
6.5 Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to the previous
issue due to the extent of the changes.
6.6 Qualification. With respect to products requiring qualification, awards will be made only for products which are, at the time of
award of contract, qualified for inclusion in Qualified Manufacturers List QML-19500 whether or not such products have actually been so
listed by that date. The attention of the contractors is called to these requirements, and manufacturers are urged to arrange to have the
products that they propose to offer to the Federal Government tested for qualification in order that they may be eligible to be awarded
contracts or purchase orders for the products covered by this specification. Information pertaining to qualification of products may be
obtained from Defense Supply Center Columbus, DSCC-VQE, Columbus, OH 43216.
