MIL-PRF-19500-477 Semiconductor Device, Diode, Silicon, Ultrafast Recovery, Power Rectifier, Types 1N5802, 1N5804, 1N5806, 1N5807, 1N5809, And 1N5811, 1N5802Us, 1N5804Us, 1N5806Us, 1N5807Us, 1N5809Us, And 1N5811Us, 1N5802Urs, 1N5804Urs, 1N5806Urs, 1N5807Urs, 1N5809Urs, And 1N5811Urs, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for silicon, fast recovery, power rectifier diodes. Four levels of product assurance are provided for each encapsulated device types as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. . . . . .
MIL-PRF-19500/477K
TABLE III. Group A, B, C, and E delta requirements. 1/ 2/ 3/ 4/ 5/
Step
Inspection
MIL-STD-750
Symbol
Limit
Unit
Method
Conditions
Duty cycle ≤ 2 percent
1.
Forward voltage
4011
(pulsed see 4.5.1); tp =
8.3 ms (max)
±50 mV dc change
ĆVFM1
1N5802, US, URS,
IFM = 1.0 A(pk)
1N5804, US, URS,
from initial value
1N5806, US, URS
±50 mV dc change
ĆVFM4
1N5807, US, URS,
IFM = 4.0 A(pk)
1N5809, US, URS,
from initial value
1N5811, US, URS
ĆIR1
2.
Reverse current
4016
DC method
100-percent or ±150
1N5802, US, URS
VR = 50 V dc
nA dc change from
1N5804, US, URS
VR = 100 V dc
initial reading,
1N5806, US, URS
VR = 150 V dc
whichever is greater.
100-percent or ±500
1N5807, US, URS
VR = 50 V dc
nA dc change from
1N5809, US, URS
VR = 100 V dc
initial reading,
1N5811, US, URS
VR = 150 V dc
whichever is greater.
Devices which exceed the table I limits for this test shall not be accepted.
1/
2/
The electrical measurements for group B inspections in table E-VIa (JANS) of MIL-PRF-19500 are as follows:
Subgroups 4 and 5, see table III herein, steps 1 and 2.
3/
The electrical measurements for group B inspections in table E-VIb (JAN, JANTX, and JANTXV) of
MIL-PRF-19500 are as follows: Subgroup 3, see table III herein, steps 1 and 2.
4/
The electrical measurements for group C inspections in table E-VII (all quality levels) of MIL-PRF-19500 are as
follows: Subgroup 6, see table III herein, steps 1 and 2.
5/
The electrical measurements for group E inspections in table E-IX of MIL-PRF-19500 are as follows:
Subgroups 1 and 2, see table III herein, steps 1 and 2.
20
