MILPRF19500/504F
TABLE I. Group A inspection Continued.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 5 Continued.
Safe operating area
3053
Load condition B,
(switching)
(clamped inductive load);
TA = +25°C; tr + tf ≤ 1.0 µs;
duty cycle ≤ 2 percent;
tp = 1 ms; (vary to obtain IC);
Rs = 0.1 Ω; RBB1 = 50 Ω;
VBB1 = 10 V dc; RBB2 = 100 Ω;
VBB2 = 1.5 V dc; VCC = 25 V dc;
IC = 20 A dc; RL ≤ 2 Ω; L = 5 mH
(Four coils in parallel, 20 mH
windings) (Triad c-48u or
equivalent).
2N6283
Clamp voltage = 80 +0, 5 V dc
2N6284
Clamp voltage = 100 +0, 5 V dc
Device fails if clamp voltage
not reached.
End-point electrical
See subgroup 2 herein.
measurements
Subgroups 6 and 7
Not applicable
1/
For sampling plan, see MILPRF19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
11
