MILPRF19500/504F
TABLE I. Group A inspection.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 1
Visual and mechanical
2071
examination
Subgroup 2
Thermal impedance 2/
3131
See 4.3.1
°C/W
ZθJC
Collector to emitter
3011
Bias condition D, IC = 100 mA dc;
V(BR)CEO
breakdown voltage
pulsed (see 4.5.1)
2N6283
80
V dc
2N6384
100
V dc
Collector to emitter
3041
Bias condition D
1.0
mA dc
ICEO
cutoff current
2N6283
VCE = 40 V dc
2N6284
VCE = 50 V dc
Emitter to base
3061
2.5
mA dc
Bias condition D, VEB = 7 V dc
IEBO
cutoff current
Collector to emitter
3041
0.01
mA dc
Bias condition A, VBE = 1.5 V dc
ICEX1
cutoff current
2N6283
VCE = 80 V dc
2N6284
VCE = 100 V dc
Base emitter voltage
3066
2.8
V dc
Test condition B, VCE = 3 V dc;
VBE
(nonsaturated)
IC = 10 A dc
Base emitter voltage
3066
4.0
V dc
Test condition A, IC = 20 A dc;
VBE(sat)
(saturated)
Collector to emitter
3071
3.0
V dc
IC = 20 A dc; IB = 200 mA dc;
VCE(sat)1
saturation voltage
pulsed (see 4.5.1)
Collector to emitter
3071
2.0
V dc
IC = 10 A dc; IB = 40 mA dc;
VCE(sat)2
saturation voltage
pulsed (see 4.5.1)
Forward-current
3076
1,500
VCE = 3 V dc; IC = 1 A dc;
hFE1
transfer ratio
pulsed (see 4.5.1)
Forward-current
3076
1,250
18,000
VCE = 3 V dc; IC = 10 A dc;
hFE2
transfer ratio
pulsed (see 4.5.1)
Forward-current
3076
500
VCE = 3 V dc; IC = 20 A dc;
hFE3
transfer ratio
pulsed (see 4.5.1)
See footnotes at end of table.
8
