MILPRF19500/504F
1.4 Primary electrical characteristics. Unless otherwise specified, TC = +25°C.
Pulse response
hFE1 (1)
VBE(sat)
VCE(sat)2
VCE(sat)1
hFE2 (1)
Limit
(2)
IC = 20 A dc
IC = 10 A dc
IC = 20 A dc
VCE = 3 V dc
VCE = 3 V dc
ton
toff
IB = 200 mA dc
IB = 40 mA dc
IB = 200 mA dc
IC = 10 A dc
IC = 1 A dc
µs
µs
V dc
V dc
V dc
Min
1,500
1,250
Max
18,000
3.0
2.0
4.0
2
10
hfe
Cobo
Limit
VCB = 10 V dc
VCE = 3 V dc
IE = 0
IC = 10 A dc
100 kHz ≤ f ≤ 1 MHz
f = 1 MHz
pF
Min
8
Max
350
80
(1) Pulsed (see 4.5.1).
(2) See figure 2 for the pulse response circuit.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
Test Methods for Semiconductor Devices.
(Copies of these documents are available online at https://assist.dla.mil/quicksearch or https://assist.dla.mil or
from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 191115094.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the
text of this document and the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
