MIL-PRF-19500/534G
27 July 2011
SUPERSEDING
MIL-PRF-19500/534F
20 July 2008
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, NPN, SILICON, POWER, TYPES 2N5002 AND 2N5004,
JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL, JANSR, JANSF, JANSG, JANSH, JANHCB,
JANKCB, JANKCBM, JANKCBD, JANKCBP, JANKCBL, JANKCBR, JANKCBF, JANKCBG, AND JANKCBH
* Reactivated after (27 July 2011) and may be
used for new and existing designs and acquisitions.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for NPN, silicon, power transistors for use in
high-speed power-switching applications. Four levels of product assurance are provided for each encapsulated
device type as specified in MIL-PRF-19500. Two levels of product assurance for each unencapsulated device type
die. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify
devices, which have passed RHA requirements.
1.3 Maximum ratings unless otherwise specified TA = +25°C.
IC
PT (1)
PT (2)
IC (4)
Reverse
VCBO
VCEO
VEBO
RθJC
RθJA
Tstg and TJ
pulse
TA = 25°C
TC = 25°C
(3)
energy
W
W
V dc
V dc
V dc
A dc
A dc
mJ
°C/W
°C/W
°C
2
58
100
80
5.5
5
10
15
88
3
-65 to +200
(1)
Derate linearly 11.4 mW/°C for TA > 25°C.
(2)
For derating see figure 3.
(3)
For thermal impedance see figure 4.
(4)
This value applies for Pw ≤ 8.3 ms, duty cycle ≤ 1 percent.
